Garden house Bodensee without sleeping loft
The Bodensee garden shed is almost identical to our Sleeping loft house Bodensee or Bodensee II – except that it has no sleeping loft in favor of greater room height. If you can do without it, this beautiful garden shed is a versatile model for your own garden, allotment or as a small guest house or vacation cabin.
With this garden shed, we can optionally offer you higher-quality deluxe windows and external doors, which have a robust glued frame construction, one-hand turn-tilt mechanism or a 3-fold locking system. 50 mm or 70 mm wall thickness is usually used for the Bodensee garden shed, but it is also available in 94 mm blockboard on request.
Article | Price | Assembly price | PDF Download |
---|---|---|---|
Bodensee 1 without sleeping loft 50mm | EUR 7,900.00 | EUR 1,950.00 | ➥ Drawing/floor plan |
Bodensee 2 without sleeping loft 50mm | EUR 8,200.00 | EUR 1,950.00 | ➥ Drawing/floor plan |
The prices quoted are cash prices and are inclusive of VAT. 19 % VAT. Assembly prices are optional, you can also order all houses without assembly. Decorations, roofing felt and assembly materials are not included in the kit price. Some of the houses shown here are custom-built and may differ from the respective standard model in terms of construction and appearance, depending on the design. Some of the log cabins shown are painted with colors that are not included in the scope of delivery and services. All dimensions are approximate and subject to change.
Technical data / equipment
Log cabin Bodensee 1 without SB 6 m x 4 m
Log house floor area 24 sqm
Side wall height 2.21 m
Ridge height 3.35 m
Log cabin Bodensee 2 without SB 6 m x 4 m
Log house floor area 24 sqm
Side wall height 2.21 m
Ridge height 3.35 m
Log cabin Bodensee 1 without SB 6 m x 4 m
Log thickness 50 mm or 70 mm with double tongue & groove
Base frame and floor support 68 x 44 mm
Floor boarding 26 mm in tongue and groove
Roof boarding 20 mm in tongue & groove
Window with 3-point turn/tilt system incl. window handles
Doors incl. lock case and door handles
Sash thickness : 42 mm
ISO glass : 18 mm - 3 / 12 / 3
Door leaf frame : glued
" all-round rubber seal" in doors / window sashes
untreated, Nordic softwood
2 windows 810 x 910, 1 double window 1200 x 910 1 window 460 x 910
1 double door 1550 x 2015 half wood half glass with a profile cylinder lock
1 interior door 700 x 1950 solid wood door with a profile cylinder lock
Log cabin Bodensee 2 without SB 6 m x 4 m
Log thickness 50 mm or 70 mm with double tongue & groove
Base frame and floor support 68 x 44 mm
Floor boarding 26 mm in tongue and groove
Roof boarding 20 mm in tongue & groove
Window with 3-point turn/tilt system incl. window handles
Doors incl. lock case and door handles
Sash thickness : 42 mm
ISO glass : 18 mm - 3 / 12 / 3
Door leaf frame : glued
" all-round rubber seal" in doors / window sashes
untreated, Nordic softwood
2 windows 810 x 910, 1 double window 1200 x 910 1 window 460 x 910
1 double door 1550 x 2015 half wood half glass with a profile cylinder lock
1 interior door 700 x 1950 solid wood door with a profile cylinder lock
1 exterior door 700 x 1820 solid wood door with a profile cylinder lock
